Product Detail

TJ-2513KF/EX

Price: US$54995

Details
Specifications


▷ Technical Specifications
Modle		TJ-2513KF/EX
Print head		Konica Minolta 1024i industrial piezoelectric print head
Basic number of Printhead		5
Maximum printhead Number		22
Row of print heads		3-rows（7/8/7）
Max printing size		2500x1300mm
Supported ink		TechJet RA-1000 / TechJet RS-1000
Colors range		(CMYK),(CMYKLcLm), (CMYK+Wh),(CMYKLcLm+Wh),(CMYK+Wh+Va),(CMYKLcLm+Wh+Va)
RIP software		ONYX、PhotoPrint、Caldera（Optional）
Print mode	Print resolution	Single-row head printing speed	Double-rows head printing speed	Three-rows head printing speed
Speed	4Pass-726×720	45.52㎡/h	80.7㎡/h	101.7㎡/h
Standard	4Pass-726×720	19.11㎡/h	35.9㎡/h	49.7㎡/h
Quality	6Pass-726×1080	12.65㎡/h	23.87㎡/h	33.9㎡/h
Ultra	8Pass-726×1440	9.5㎡/h	18㎡/h	25.4㎡/h
Dimension(W x D x H)		4846mmx2200mmx1487mm
Printer weight		1800kg
Maximum printing thickness		50mm
Max media weight		50kg/㎡
interface		Standard USB Interface
Curing device		Dual UV-LED lamps
Ink supply method		Vacuum negative pressure, continuous ink supply
Power requirement		AC220V±10%,≥32A,50/60HZ
Max/Min. power		7000W / 5000W
Printable environment		Temperature 15-30℃，Humidity 30%-70%RH(non condensing)
The above printing speed is the measured printing speed
