HOME >> PRODUCTS >>Roll to Roll UV Printers >> TJ-3300RA-Ultra
Product Detail

TJ-3300RA-Ultra

Price
US$79995
  • Details
  • Specifications



▷ Technical Specifications
ModelTJ-3300RA-Ultra
Print headKonica Minolta 1024a industrial piezoelectric print head
Basic number of printhead4
Maximum printhead number16
Row of print heads3-rows
Maximum print size3300mm
Supported inkTechJet FV-1000
Colors range(CMYK),(CMYKLcLm), (CMYK+Wh ),(CMYKLcLm+Wh )
RIP SoftwareONYX、PhotoPrint、Caldera(optional)
Print modePrint resolutionSingle-row head printing speedDouble-rows head printing speedTriple-rows head printing speed
Speed4Pass-726×72055.7㎡/h105.83㎡/h161.53㎡/h
Standard4Pass-726×72030.5㎡/h57.95㎡/h88.45㎡/h
Quality6Pass-726×108020.57㎡/h39.08㎡/h59.65㎡/h
Ultra8Pass-726×144015.98㎡/h30.36㎡/h46.34㎡/h
Dimension(W x D x H)5650mmx1300mmx1650mm
Printer weight2700kg
Maximum printing thickness2mm
Max media weight120kg
interfaceStandard USB Interface
Curing deviceDual LED-UV lamps
Ink supply methodVacuum negative pressure, continuous ink supply
Power requirementAC220V±10%,≥30A,50/60HZ
Max/Min. power6000W / 4000W
Printable environmentTemperature 15-30℃,Humidity 30%-70%RH(non condensing)
The above printing speed is the measured printing speed
