▷ Technical Specifications
Print headPrint head typeMicro piezo print head
Number of printhead24
Print resolution720×1200dpi、720×1800dpi、720×2400dpi
Print head protectionAutomatic cleaning, automatic inkjet moisture function
Printing speed4PASS 720×1200dpi(Speed)40.5 ㎡/h76.8 ㎡/h
6PASS 720×1800dpi(Standard)24.4㎡/h51㎡/h
8PASS 720×2400dpi(Quality)17.63㎡/h38.4㎡/h
InkTypeWater-Based dye ink
color rangeC M Y K
ModelTW11-1000,Package of 1000ml each
Maximum print size1800mm
MediaPP self-adhesive sticker, Photographic paper, Silk cloth
Media typeRoll media
RIP softwareMaintop
Supported image formatsJPG、TIF、BMP、PDF
Computer ConfigurationOperating SystemWin7、Win10
Hardware RequirementsHard disk: 500G or more, Graphics: ATI Solo, RAM:8G , Optical drive: DVD optical drive, inter  core i5
InterfaceNetwork Interface
StandardFront built-in heating + external dryer, automatic paper collector, Maintop RIP
Printable environmentHumidity: 40%-60%(non condensing),Temperature∶15℃~35℃
Power220V  50/60HZ  10A
Machine Size(W×D×H)3080×800×1530mm3018×853×1538mm
Package Size(W×D×H)3190×1010×1090mm3190×1010×1020mm
Package SizeNet weight:330KG
Gross weight:485KG
Net weight:350KG
Gross weight:510KG
The specification are subject to change without notice
