Product Detail

2513HG-Ultra Flatbed UV Printer

Details
Specifications

Ricoh G6 / G5 PrintHead MSRP：49,995.00 USD

•Maximum 4 rows of printheads can be loaded.

•The maximum print media thickness up to 250mm, make it compatible with a wider range of materials and applications.

•Equipped with a brand-new collision avoidance system, effectively protects the print head even during high-speed printing.

Model		2513HG-Ultra
Carriage moving approach		Linear Motor
Print head		Ricoh G5/G6
Basic and Max number of printheads		3--12
Maximum printheads number		12
Max Row of printheads		4
Used ink		TechJet RA-1000
Colors range		4 Colorsx4=CMYKX4
		6 Colorsx4=CMYKLcLmx4
		4 Colorsx2 +Whitex2=CMYKx2+Whitex2
		6 Colorsx2+Whitex2=CMYKLcLmx2+whitex2
		4Colorsx2+White+Varnish
		6 Colorsx2+White+Varnish
Print mode	Print resolution	Two rows printhead printing speed	Three rows printhead printing speed	Four rows printhead printing speed
Draft Mode	4Pass-726×600	67.6㎡/h	89.3㎡/h	109.3㎡/h
Standard mode	4Pass-726×600	31.2㎡/h	43.8㎡/h	53.9㎡/h
Quality Mode	6Pass-726×900	20.6㎡/h	29.3㎡/h	36.6㎡/h
High quality mode	8Pass-726×1200	15.6㎡/h	22㎡/h	27.6㎡/h
Print Media	Max Print size	Up to 2500×1300mm(8.2Fx4.3F)
	Thickness	Up to 250mm
	Max.weight	50Kg/㎡
RIP Software		ONYX、PhotoPrint、Caldera（Optional）
Data interface		USB3.0
Ink supply method		Vacuum negative pressure, continuous ink supply
Curing Method		Dual UV-LED Lampes
Gross weight		1300KG
Dimension (W x D x H)		4530mm×2200mm×1560mm
Power requirement		AC220V±10%，≥32A，50/60HZ
Maximum power		7000W
Printable environment		Temperature 20-30 °C, humidity 40%-60%RH (non condensing)
Remark The above printing speed is the measured printing speed. The power consuption basicis on standby and normal print. *The printing speed basis just 4 colors and 6 colors model not involved the white and varnish.
