3300VersaUV Printer

  • Details
  • Specifications


Konica Minolta 1024a PrintHead                                                                                                                    MSRP:79,995.00 USD


The front and back extending platforms are optional parts that can be quickly assembled and disassembled, it enables the printer to print both roll and board media.


Loading Konica Minolta 1024a printhead with special developed UV inks, efficiently raise print speed and also quality.

Widely used in advertising production and other fields.

Using a high torque and high-precision reducer to drive the mesh belt, combined with vacuum table, to ensure the stability and flatness of media movement.

Tension feeding and discharging system,ensure media feeding stable without wrinkle.

Automatic negative pressure adjustment system continuously provides stable pressure to ensuring the stability of the ink supply.

Intelligent lacking ink voice alarm, ensuring printing process safer and more reliable.


Carriage moving approachLinear Motor
Print headKonica Minolta 1024a / 6988H
Basic and max number of printheads5--22
Maximum printheads number22
Max row of printheads3
Used inkTechJet F2-1000
Colors range4 Colorsx3=CMYKx3
6 Colorsx3=CMYKLcLmx3
4 Colorsx2 +White =CMYKx2+White
6 Colorsx2+White =CMYKLcLmx2+white
4 Colors +White+Varnish
6 Colors +White+Varnish
Print modePrint resolutionOne row printhead printing speedTwo rows printhead printing speedColor white color printing speed (Three-rows printhead)
Draft Mode4Pass-726×72081㎡/h81㎡/h40.5㎡/h
Standard mode4Pass-726×72042.42㎡/h42.42㎡/h21.21㎡/h
Quality Mode6Pass-726×108028.4㎡/h28.4㎡/h14.2㎡/h
High quality mode8Pass-726×144021.4㎡/h21.4㎡/h10.7㎡/h
Print MediaMediaRoll mediaFlat media
Max Print sizeUp to 3300mmUp to 3200×1300mm
ThicknessUp to 1.5mmUp to 30mm
RIP SoftwareONYX、PhotoPrint、Caldera(Optional)
Data interfaceUSB3.0
Ink supply methodVacuum negative pressure, continuous ink supply
Curing MethodDual UV-LED Lampes
Gross weight2700kg
Dimension (W x D x H)5620mm×1460mm×1630mm
Front and back printing platform(optional accessories)3500mm×565mm
Power requirementAC220V±10%,≥32A,50/60HZ
Maximum power7000W
Printable environmentTemperature 20-30 °C, humidity 40%-60%RH (non condensing)
*The above printing speed is the measured printing speed.
*The power consuption basicis on standby and normal print.
*The printing speed basis just 4 colors and 6 colors model not involved the white and varnish.
